TRACTOR INSTRUMENTS
C
14
▶ PTO LEVER
PTO shift lever has 3 positions, rear, mid
and rear & mid. (mid PTO is option)
<Examples of useful conditions
of 4WD>
The 4WD can be used under the
following conditions :
1. When cultivating in a field.
2. When traction is required on a slope,
in a wet field or for towing a trailer.
3. When working in a wet or sandy
field.
4. When cultivating on firm soil with a
rotavator to prevent the tractor
from being pushed forward.
5. When driving into/out of a field or
going over a field bank.
▶ 4WD LEVER
• 「ON」–
Push forward 4wd lever to the 「ON」
position to engage 4WD.
• 「OFF」–
Push backward 4wd lever to the
「OFF」 position to disengage 4WD.
4WD LEVER
PTO LEVER
Before operating the 4WD lever, make
sure to stop the tractor.
If it is hard to engage the 4WD lever, do
not apply excessive force to it. Instead,
drive the tractor forward or backward
slightly and try it again.
Avoid using 4WD on public roads to
reduce wear on tires.
IMPORTANT
Turn off PTO switch before changing
PTO shift lever position.
IMPORTANT
PTO RPM
REAR 540
MID 2,000
