E
MAINTENANCE
20
<Adjusting front wheel tread>
The tread can be adjusted by switching
the rims and discs on the left and right
sides.
<Adjusting rear wheel tread>
The tread can be adjusted by switching
the rims and discs on the left and right
sides.
Possible combination of rear wheel with
front wheel table.
▶ ADJUSTING TREAD
▶ STANDARD FOR TREAD ADJUSTMENT
 For safety, have tread adjustment
performed by your dealer or workshop.
 Never remove tires if there is no safe
supporting device. The tractor can roll
over.
WARNING
REAR
FRONT
A A
B A B C
C A B C D
D B C D E F G
E D E F G
F F G
UNIT : mm
(STANDARD)
(STANDARD)
