E
MAINTENANCE
28
1. Unscrew the Water pump mounting
bolts slightly and move the water
pump to adjust the tension of the
belt.
2. Check the belt tension.
Press the center of the belt.
If it is deflected for 7 ~ 9 mm, it is
normal.
▶ CHECKING AND ADJUSTING
WATER PUMP BELT
Check and adjust the tension of the A/C
compressor belt regularly.
1. Unscrew the tension adjusting bolt
of the compressor belt.
2. Pull the bolt to adjust the tension.
Then, tighten the bolt.
3. Press the center of the belt with a
filter.
If it is deflected for 7 ~ 9mm, the
tension is proper.
1. Unscrew the alternator mounting
bolts slightly and move the
alternator to adjust the tension of
the belt.
2. Check the belt tension.
Press the center of the belt.
If it is deflected for 7 ~ 9 mm (2.7 ~
3.5 inch), it is normal.
▶ CHECKING AND ADJUSTING A/C
COMPRESSOR BELT
▶ CHECKING AND ADJUSTING FAN
BELT
BOLT
BOLT
ADJUSTING
BOLT
7 ~ 9mm
ADJUSTING
BOLT
7 ~ 9mm
ADJUSTING BOLT
