C
TRACTOR INSTRUMENTS
6
This device is used to select the driving
direction between the forward and
reverse directions.
• Set it in the neutral position unless
driving.
• With the lever 1 pulled up slightly
(Feeling a slight spring tension),
push it forward (A) to select forward
driving and pull it backward (B) to
select reverse driving.
▶ SHUTTLE SHIFT LEVER
(1) Lamp selection lever
• This lever is to operate the
headlamps, horn and turn signal
lamps.
• Position lamp
Turn the lever (A) from the position
(1) to (2).
• Horn
Press the tip of the lever in the arrow
direction.
▶ COLUMN SWITCH LEVER
Before starting the engine, set the
shuttle shift lever in the neutral position
and depress the clutch pedal fully to
avoid an accident by abrupt starting off.
WARNING
The shuttle shift lever consists of electric
components, so forcible operation can
damage the lever.
Poor fuel quality can damage the engine.
Make sure to use only the specified
genuine diesel fuel.
Use fuel for winter season in winter to
enhance engine starting performance.
IMPORTANT
