C
TRACTOR INSTRUMENTS
14
(24) 1st trailer turn signal indicator
This comes on when the trailer is
connected and the tractor turn signal
lamp is activated.
(25) 2nd trailer turn signal indicator
This comes on when the trailer is
connected and the tractor turn signal
lamp is activated.
(26) 4WD indicator
This comes on when the 4WD is
activated.
(27) Quick turn indicator (Optional)
This comes on while the quick turn
function is in use.
(28) Engine oil pressure warning lamp
The lamp comes on when an engine oil
lubrication problem occurs. Stop the
engine and check the engine oil level or
get help from a workshop.
If lowering an implement or releasing
the driving clutch pedal with the PTO
indicator blinking, the rotating PTO
shaft can cause a dangerous situation.
Make sure that no one comes within the
turning radius of the tractor.
WARNING
When the oil pressure warning lamp
comes on, this indicates malfunction of
the lubrication system. Check the
engine oil immediately and have your
vehicle serviced by your workshop as
necessary.
IMPORTANT
1
ST
TRAILER TURN SIGNAL 2
ND
TRAILER TURN SIGNAL
INDICATOR INDICATOR
4WD INDICATOR QUICK TURN INDICATOR
ENGINE OIL PRESSURE HYDRAULIC CLUTCH LOW
WARNING LAMP PRESSURE WARNING LAMP/
STRAINER CLOGGING
WARNING LAMP
