2 - 1
2
DESCRIPTION OF OPERATION SYSTEM
Joystick lever
Throttle lever
PTO switch
Steering wheel
Driving
clutch pedal
Brake pedal
PTO Shift lever
Main shift
lever
External
hydraulic
control lever
Throttle
pedal
Parking brake
(hand brake)
j10o314a
Electronic
lift control
Range
shift lever
TCU switch
panel
2-1. CONTROLS (SP MODEL)
Power
socket
External
power
connector
Shuttle shift lever
Column switch
•
Turn signal lamp
•
Horn
•
Head lamp
