<General Information>
• general Information
Our new engine applies all
applicable advanced technologies to
satisfy the tightened restrictions
exhaust, while also improving fuel
efficiency and reducing exhaust gas.
The exhaust reduction system
features a diesel oxidation catalyst
(DOC) device to reduce soot particles
and an exhaust gas recirculation
(EGR) system and (SCR) system to
reduce the nitrogen oxide (NOx) from
the engine exhaust gas.
1. The EGR system is a device that
recirculates exhaust gas to reduce
NOx emissions.
2. The muffler has a diesel oxidation
catalyst (DOC) device in it.
- This DOC device reduces HC and
CO emissions in exhaust gas with
reduction catalysts.
3. SCR is used to reduce NOx in
emissions by spraying urea into the
SCR catalyst.
▶ INTAKE/EXHAUST SYSTEM
(9) AdBlue® Temperature Sensor
(10) AdBlue® Level Sensor
(11) Dosing Control Unit
(12) Actuators
(13) Sensors
(14) Engine CAN
(15) Diagnostic CAN
(1) Diesel Engine
(2) Dosing Module with Injector
(3) Temperature Sensor
(4) SCR Catalyst
(5) Temperature Sensor
(6) Filter
(7) AdBlue® Supply Module
(8) AdBlue® Tank
Note) SCR; Selective Catalytic Reduction
