4.1 Monitor Installation
4.2 Sensor Installation
Install the monitor in a place where it is easy to see in the car. The user can directly paste
the monitor on the dashboard with double-sided tape or put up a suction cup in the
appropriate position of the windshield to attach it. Then connect one end of the cigarette
lighter charger to the monitor and the another end to the cigarette lighter in the car to
power it on.
1. The monitor should be installed in a position where it will not affect the driving vision.
2. The monitor should be reinforced to avoid falling during driving.
3. When checking the displayed pressure and temperature values while driving, please
pay attention to driving safety .
4. This product will automatically detect the tires and sound an alarm, so the driver does
not need to pay frequent attention to it so as not to be distracted while driving.
The sensor ID code has been paired before leaving the factory. The sensor can be
installed on the tire directly at the corresponding position when installing, and can be used
directly. The standard configuration is one monitor paired with 4 sensors，and each
sensor uses stickers (front left, rear left, front right, rear right) to indicate the
corresponding tire position. If there is a spare tire in the vehicle, a sticker (backup) is
required to indicate the position of the spare tire. When installing, please carefully read the
user instruction to paste the label stickers (as shown in Figure 2) to corresponding tires.
4. Installation Guides
Notice：
Corresponding Tire Position Diagram for Sensor Installation:
