Installation Position Diagram:
Please install the monitor and sensor that have been equipped at the factory into the
vehicle. If there is an error code or the position of the sensor is forgotten during the
assembly process, you can re-code with the "inflatable code". (Refer to the user instruction
of the monitor for details on the operation of the inflatable code.)
Notice：
Notice：
Before installing the sensor, please make sure to turn on the monitor so that the data can
be sent to the monitor in time after the sensor is installed.
Notice：
1. Each sensor uses a sticker to indicate its tire position, and it must be accurately
installed on the corresponding tire.
2. When the voltage of the sensor battery is low, there will be a low voltage alarm on the
monitor.
3. After the sensor is installed, please check whether there is any air leak in the tire. If
necessary, use soapy water to wipe the tire valve to check.
1. First install the anti-theft hex nut into the thread of the car tire valve core.
2. Tighten the transmitter clockwise to the thread of the car tire valve core.
3. Use a clamp to tighten the anti-theft hex nut counterclockwise to the transmitter to
activate the anti-theft function.
The sensor installation steps are as follows.
Figure 2
Front Left Front Right
Rear Left Rear Right
Anti-theft Hex Nut
Anti-theft Hex Nut
Tire Valve Core
Transmitter
