13
Hyper Memory Keys
([A] - [F])
1. The outer VOL (Volume) control adjusts the "right" receiver speaker audio level.
2. Press and hold this knob for 1/2 second to turn the radio "on" and "off".
3. The inner SQL (Squelch) control adjusts the "right" receiver background noise.
8
5
RIGHT [HM]
(Default)
RIGHT [TONE]
(Key Mode 2)
RIGHT [SCN]
(Default)
RIGHT [SUB]
(Key Mode 2)
1. Short press the key to recall a favorite "HOME" frequency memory.
2. Press and hold in this key for 1/2 second to activate Priority Channel Scanning under VFO or MR mode.
Short press the key to change the Tone Squelch mode: ENC (CTCSS Encoder), ENC DEC (CTCSS
Encoder & Decoder) or DCS operation.
1. Short press the key to activate the Scanner on the "right" band.
2. Press and hold in this key for 1/2 second to set up the Scan Skip List or Preferential Scan List under MR mode.
Short press the key to make the next key you press act on the "Sub band". (The " " icon will blink
on the "Sub band")
6 RIGHT VOL/SQL
1. Tuning dial for the "right" band.
2. Short press the knob to set the right band as the "Main" band.
3. Enable rapid tuning (in 1 MHz steps) when the "right" band is set to be the Main band in VFO
mode.
4. Press and hold in this knob for 1/2 second to toggle the operating band between 144 MHz and 430
MHz on the right side.
1. Press and hold in one of these buttons for 2 seconds to store the current configuration of the radio
into a special "Hyper" memory bank.
2. Short press the appropriate button to recall the desired "Hyper" memory.
RIGHT DIAL7
14
Display
12
13
14
15
16
17
18
19
20
21
Icon
Memory Tune Mode
Audio Mute Activate
DCS On
AM Reception
Low Power Output
Middle Power Output
Automatic Power-Off
Keypad/Dial Lock
Menu Set
Key Mode 2 active
FUNCTIONNO.
1
2
3
4
5
6
7
8
9
10
11
Icon
Memory Channel Number
Preferential Memory Channel
Skip Memory Channel
Minus Shift
Plus Shift
Odd Splits
CTCSS Encoder On
CTCSS Decoder On
Transmitting
"Main" Band
Busy Channel (or Squelch Off)
FUNCTIONNO.
To Next Page
