PAGE 8 OF 24 0322 IH-9730
L-DESK RETURN ASSEMBLY CONTINUED
19. With second person, hold center drawer (G) in
the desired location on the desktop or return top.
Use four ST 5 x 16 mm self-tapping wood screws (D)
to secure. (See Figure 22)
NOTE: Drawer holes can be started with drill.
(optional)
NOTE: It is recommended to have drawer flush
with front edge of desktop panel.
20. Adjust glides to compensate for uneven floors.
L-desk is now fully assembled.
Figure 22
D
G
Completed Assembly
