U-Line Origins Series User Manual

41
*Parts included in the 150 faceplate assembly.
Item Description White Black Stainless
- Ice Maker Assembly 402 402 402
- Faceplate Assembly 150 150 150
1 Cover 627000 627000 627000
2 Gear 628210* 628210* 628210*
3 Motor 627973* 627973* 627973*
4 Spring 627163* 627163* 627163*
5Valve Switch Plate 625836* 625836* 625836*
6 Switch Spacer 625834* 625834* 625834*
7 Cam 627302* 627302* 627302*
8 Insulator 627680* 627680* 627680*
9 Hold Switch 2506* 2506* 2506*
10 Limit Switch 2579 2579 2579
11 Valve Switch 2506* 2506* 2506*
12 Support Housing 625827 625827 625827
13 Bin Arm 2603 2603 2603
14 Bin Arm Spring 627526 627526 627526
15 Ejector 627375 627375 627375
16 Mold Heater 625843-S 625843-S 625843-S
17 Stripper 31400 31400 31400
18 Stripper Screw 489128
De
489128
Description
489128
Part No.
19 Mold & Heater Assembly 628123-S 628123-S 628123-S
20 Water Cup 544304 544304 544304
21 Spring & Housing Screw 488372* 488372* 488372*
22 Gear Screw 488957* 488957* 488957*
23 Face Plate 11641* 11641* 11641*
24 Plate Screw 41375 41375 41375
25 Long SW Screw 488361* 488361* 488361*
26 Short SW Screw 488362* 488362* 488362*
27 Bin SW Screw 488360 488360 488360
28 Clamp 625829 625829 625829
29 Arm Lever 625830 625830 625830
30 Arm Lever Screw 627199 627199 627199
31 Motor Screw 488622* 488622* 488622*
32 Bin Switch 2506 2506 2506
220V Motor 628109 628109 628109
220V Mold Heater 626069-S 626069-S 626069-S
220V Mold & Heater Assembly 618 618 618
220V Faceplate Assembly 650 650 650
220V Ice Maker Assembly 619 619 619
MODEL 402 ICE MAKER
