10
User’s Manual
Figure 10
4. Place the two hook-hinges (located on the rear bottom side of the
grille) on the front lip of the unit base. Swing the grille up into posi-
tion, aligning the grille and cabinet screw holes (see Figure 11).
Figure 11
5. Insert the screw, being careful not to over tighten.
6. Reinstall control knob.
UL107
UL106
GRILLE SCREW
Users Manual 41923 9/2/03 3:44 PM Page 10
