20
User’s Manual
Install the insert as follows:
Insert edges may be SHARP! Use care when installing.
1. Remove top hinge screw pin (large Phillips head, see Figure 28).
Hold door to keep it from falling.
2. Remove door, being careful not to scratch top of door on hinge.
3. Pull door gasket out of groove (top edge of door only). Start in the
middle and pull outward, moving toward the edge (see Figure 29).
This may take some force.
4. Remove two small screws
holding door handle. Slightly
separate door handle from
door (see Figure 30).
5. Pull handle up and off.
UL131
UL132
Figure 28
UL117
Figure 30
Figure 29
Users Manual 41923 9/2/03 3:44 PM Page 20
