16 17
LIGHTING
LED Headlight 120mm 4.75” diameter
Low beam 1330 lumens 27.6W
High beam 2230 lumens 36W
Additional lighting LED rear, brake, number plate and
directional lights
PERFORMANCE
Range Max range varies depending on
terrain and carry load
Power 2.4kWh
Torque 184Nm
Top speed 50km/h 30mph
VEHICLE CLASS
NZ/AUS LA (moped)
US Motor driven cycle or moped
EU L1Be
WARRANTIES
Dual-use 2018 2×2 12 months
Portage Power Supplies 24 months
Accessories 12 months
Spare Parts 6 months
Technical Specifications
DIMENSIONS
Height* (excl mirrors) 1,050mm 42"
Length* (excl number plate) 1820mm 72"
Width (handlebars) 800mm 31.5"
Wheel base 1,200mm 47"
Seat height 800mm 31.5"
Curb weight 63kg 139lbs
Carry capacity (incl rider) 150kg 330lbs
ELECTRICAL SYSTEM
Motor 2x 1kW brushless DC air cooled
hub Flux Drive motors
Controller 2x high power density controllers
with over-heating protection
Power pack Ubco lithium-ion 52.2Ah (48Ah
rated) 50V battery
Charger type 100-240V 350W wall or bench
mount
Charge time 6-8 hours
Input Bluetooth with user app/USB
Ports 2x USB charging ports (1A & 2.5A)
1x 12V outlet (10A max)
COMMUNICATION
Integrated ECU Directly controls lighting, motor
controllers, display, rider controls,
Bluetooth connection
DRIVETRAIN
Transmission Single Stage Planetary Gear
Reduction
Integrated radiator for enhanced
heat dissipation
CHASSIS / SUSPENSION / BRAKES
Front suspension 37.5mm custom Ubco front fork
with rebound adjustment
Rear suspension 32mm shock with adjustable spring
preload and rebound damping
Front suspension travel 130mm
Rear suspension travel 120mm
Brakes Tektro Dorado front and rear
brakes, 203 x 2.3mm rotors, high
power hydraulic calipers
Wheels 17 x 1.85” aluminium rims
17 x 2.75” Kenda K667 tyres
*Height / Length measures are approximate.
Directional indicators, reflectors, rear light, number plate holder and mirrors on the road version only.
All product specifications are subject to change without notice to improve performance, function and/or design.
