Ubee DDW365

Ubee Interactive Using the Setup Option
Ubee DDW365 Advanced Wireless Gateway Subscriber User Guide • February 2014 30
Label Description
LAN
IP Address Defines the local IP address, which is the default gateway
address for all wired LAN hosts that connect to the DDW365.
MAC Address Displays the LAN interface’s hardware address.
Interface/Prefix
None Specified Indicates no interface or prefix has been specified.
WAN
IP Address Displays the current WAN public IP address obtained from the
service provider.
MAC Address Displays the WAN interface’s hardware address.
Duration Displays the accumulated time since successfully acquiring a
WAN public IP address.
Expires Displays the remaining time before the WAN IP address
expires, if applicable.
Release WAN Lease Releases the WAN public IP address when clicked.
Renew WAN Lease Renews the WAN IP address when clicked.
