Ubee Interactive Using the Forwarding Option
Ubee DDW365 Advanced Wireless Gateway Subscriber User Guide • February 2014 48
6. Click Apply. The forwarding rule is created and displayed in the table as shown
below. Additional field descriptions follow.
6.5.3 Setting Up Forwarding for an Xbox Example
Following is an example of how you would set up a single Xbox running Modern
Warfare 2. Since multiple ports are used for the Xbox and the Modern Warfare 2 game, a
separate forwarding rule is set for each port. Multiple ports and forwarding rules may not
be required for other applications.
To set up port forwarding for an Xbox:
1. Click Advanced from the main menu.
2. Click Forwarding from the left side menu.
3. Enter the Xbox IP address in the Local IP field.
4. Define ports used by the Xbox in the Local Start Port and Local End Port fields.
Define the same ports used by the Xbox in the External Start Port and External End
Port fields.
5. Create Port Forwarding rules per port. A rule set up for port 53 works for port 53. A
Port Map Shows a list of common applications and their ports.
Forwarding Table – Lists existing forwarding rules.
Remove All Deletes all entries in the forwarding table.
Label Description
Edit Displays fields for the rule selected in order to change values.
Remove Deletes the rule selected.
