Ubee Interactive Using the DMZ Host Option
Ubee DDW365 Advanced Wireless Gateway Subscriber User Guide • February 2014 54
To set up a DMZ host:
1. Connect a PC to an Ethernet port on the DDW365. Make sure both devices are
powered on and functioning.
2. Connect a Home Gateway (or other device you wish to be in the DMZ) to an Ethernet
port on the DDW365.
3. Log in to the DDW365 Web user interface.
4. Click Advanced from the main menu.
5. Click DMZ Host from the left side menu.
6. Enter the IP address of the Home Gateway (host device) to be exposed to the WAN.
7. Test the device to ensure Internet access is available and the device is functional. For
example, connect to the Internet from a PC connected to the Home Gateway.
Label Description
DMZ Address Defines the IP address of the host to be exposed.
Apply Saves changes.
