Ubee DDW36C User Manual

Ubee Interactive Using the Primary Network Option
Ubee DDW36C Advanced Wireless Gateway MSO Operations Guide • October 2015 78
Label Description
2.4GHZ / 5GHz (top left side) On the top left side of the screen, you can select either the
2.4GHz or 5GHz radio band to configure.
MAC ID Displays the MAC Address of the DDW36C.
Primary Network Enables or disables the primary network.
Network Name (SSID) Defines the primary network name (SSID) to which client
devices connect.
-- For the 2.4GHz radio (shown above), the default SSID is
“WIFI” plus the last 6 characters of the MAC address with
the letters in UPPER case.
-- For the 5GHz radio, the default SSID is “WIFI” plus the
last 6 characters of the MAC address with the letters in
UPPER case, plus “-5G”.

Ubee DDW36C Specifications

General

Brand	Ubee
Model	DDW36C
Category	Gateway
Language	English
