Ubiquiti EdgeRouter X ER-X User Manual

Passive PoE Passthrough
The EdgeRouter X can be powered by either method:
• Power adapter
• 24V passive PoE on the eth0/PoE Inport
Passive PoE output on port eth4/PoE Out works as a
passthrough and depends on the input power source.
If the included Power Adapter (12V, 0.5A) is used, there may not
be sufficient passthrough to power another device because
the EdgeRouter X can consume up to 5 watts on its own.
We recommend using a more powerful input power source
(not included); here are a few examples of viable power input
options for passive PoE passthrough:
Power Input Passive PoE Passthrough
24V passive PoE (on eth0/PoE In)* ≈23V, 5W
12V, 1A
(ERLite-3 Power Adapter)
≈11V, 5W
24V, 2.5A
(ERPoe-5 Power Adapter)
≈23V, 11W
* Not compatible with 24V, 1A Gigabit PoE Adapter.

Ubiquiti EdgeRouter X ER-X Specifications

General

Model	EdgeRouter X ER-X
Category	Network Router
Ports	5 x Gigabit Ethernet
Processor	Dual-Core 880 MHz MIPS1004Kc
RAM	256 MB DDR3
Flash Storage	256 MB NAND
Max Power Consumption	5W
Operating System	EdgeOS
Operating Temperature	-10 to 45° C (14 to 113° F)
Operating Humidity	10 to 90% Noncondensing
Certifications	CE, FCC, IC
Switching Capacity	1 Gbps
Power Input	12V DC, 0.5A
Power Method	Passive PoE
Dimensions	110 x 75 x 22 mm (4.33 x 2.95 x 0.87 in)
