Ublox SARA-R410M-02B-00 User Manual

SARA-R4/N4 series-AT Commands Manual
UBX-17003787 - R09

8Security
Page 62 of 307
8Security
8.1Enter PIN +CPIN
+CPIN
SARA-R404M SARA-R410M-01B SARA-R410M-02B SARA-R410M-52B SARA-R412MModules
SARA-N4
Syntax PIN required Settings saved Can be aborted Response time Error referenceAttributes
full No No No < 10 s +CME Error
8.1.1Description
Enter PIN. If no PIN request is pending, the corresponding error code is returned. If a wrong PIN is given three
times, the PUK must be inserted in place of the PIN, followed by the <newpin> which replaces the old pin in
the SIM.
8.1.2Syntax
Type Syntax Response Example
Set AT+CPIN=<pin>[,<newpin>] OK AT+CPIN="0933"
OK
Read AT+CPIN? +CPIN: <code>
OK
+CPIN: SIM PIN
OK
Test AT+CPIN=? OK
8.1.3Defined values
Parameter Type Description
<pin>, <newpin> String 4-to-8 characters long string of decimal digits.
If only PIN is required, <newpin> is not to be entered.
If PUK is required, <pin> must be the PUK and <newpin>, the new PIN code, must be
entered as well.
<code> String
• READY: MT is not pending for any password
• SIM PIN: MT is waiting SIM PIN to be given
• SIM PUK: MT is waiting SIM PUK to be given
• SIM PIN2: MT is waiting SIM PIN2 to be given
• SIM PUK2: MT is waiting SIM PUK2 to be given
• PH-NET PIN: MT is waiting network personalization password to be given
• PH-NETSUB PIN: MT is waiting network subset personalization password to be
given
• PH-SP PIN: MT is waiting service provider personalization password to be given
• PH-CORP PIN: MT is waiting corporate personalization password to be given
• PH-SIM PIN: MT is waiting phone to SIM/UICC card password to be given
8.1.4Notes
• The command needs the SIM module to work correctly
• If PIN is not inserted the following situation can occur:
AT+CMEE=2
OK
AT+COPS=0
+CME ERROR: SIM PIN required
AT+CMEE=0
OK
