S9600-72XC Hardware Installation Guide | 6
Component Physical Information
Specification Item Description
Weight
Total package contents 60.59bs (27.54kg)
Chassis without FRU 50.86lbs (23.12kg)
Power Supply Unit (PSU)
DC PSU: 2.2lbs (1.0kg)
AC PSU: 2.6lbs (1.2kg)
Fan module 1.1lbs (498g)
Ground lug 0.146lbs (66.2g)
Adjustable mounting rail
Micro USB cable 0.05lbs (24.4g)
RJ45 to DB9 female cable 0.27lbs (123.9g)
AC power cord (AC version only) 0.7lbs (318g)
Dimension
S9600-72XC (W x D x H)
17.16” x 24” x 3.45”
(436 x 609.6 x 87.6mm)
PSU (W x D x H) 1.99” x 12.64” x 1.58” (50.5 x 321 x 40.2mm)
Fan (W x D x H) 3.15” x 4.8” x 3.15” (80 x 122 x 80mm)
SMB To BNC Converter Cable 0.07lbs (32g)
SMB To BNC Converter Cable 3.94”~11.8" (10~30cm)
