OVERVIEW
- 2 -
1.3.2. Measuring unit
Measuring unit
GP-H
GP-BH
（
Conversion cable 2m
）
Sensor head
WP-01, WP-02, WP-03, WP-16
WPB-10, WPB-10-034
Weight 35g
GP-BH: 0.13kg
Conversion calbe: 0.2kg
*Because of its circuitry, the indication of this vacuum gauge varies with the type of sensor head.
Therefore, if the type of sensor head is changed after delivery, re-adjustment will be required. Before
operation, check the conditions at the time of shipment from the factory (type of sensor head) that are
indicated on the measuring unit.
1.3.3. Sensor head cable
Sensor head cable
2, 5, 10, 15, 20, 30, 50, 100m
Weight(kg)
0.2, 0.4, 0.7, 1.0, 1.3, 1.9, 3.9, 7.7
1.3.4. Others
Test results certificate
Calibration certificate
Calibration certificate, JCSS Calibration certificate
Because of its circuitry, the indication of this gauge varies with the type of
sensor head and sensor head cable length. Therefore, if the type of sensor
head or sensor head cable length is changed after delivery, re-adjustment will
be required.
Before operation, check the conditions at the time of shipment from the factory
(type of sensor head) that are indicated on the rear panel.
