Ungo ProSecurity K20 - Page 30

Ungo ProSecurity
151
RK1: Remote Start/Keyless Entry System
Main Harness
Wire Color Function
Orange Ground When Armed (-) 500mA
White (+/-) Parking Light Output
White/Blue (-) Activation Input
Black/White (-) 200mA Domelight Supervision Output
Green Not Used
Blue (-) Second Unlock Output
Violet Not Used
Black (-) Chassis Ground
Brown (-) Horn Output
Red (+) Constant Power
Red/White (-) 200mA Channel 2 Auxiliary Output
4-Pin Harness
Wire Color Function
Lt. Green/Black (-) Factory Alarm Disarm
Gray/Black (-) Wait-to-Start Input
Green/White (-) Factory Alarm Rearm
Violet/Black (-) 200mA Channel 4 Auxiliary Output
5-Pin Harness
Wire Color Function
Black/White (-) Neutral Safety Input
Violet/White Tachometer Input
Brown (+) Brake Shutdown Input
Gray (-) Hoodpin Shutdown Input
Blue/White (-) 200mA 2nd Status / Rear Defogger Output
Relay Satellite
Wire Color Function
Purple (+) Starter Side Starter Wire (Output)
Green (+) Key Side Starter Wire (Input)
Red (+) 12v Constant Input
Orange (+) Accessory Output
Red (+) 12v Constant Input
Pink (+) Ignition Output
Red/White (+) 12v Constant Input
Pink/White (+) 2nd Ignition Output
4-Pin Harness on Relay Satellite
Wire Color Function
Pink (-) 200mA 3rd Ignition Output
Violet (-) 200mA Starter Output
Orange (-) 200mA 2nd Accessory Output
Blue (-) Status Output
3-Pin 2-Wire Door Lock Harness
Wire Color Function
Green (-) Lock, (+) Unlock Output
Empty
Blue (-) Unlock, (+) Lock Output
