RS10: Remote Start/Keyless Entry System
Main Harness
Wire Color Function
White (+/-) Parking Light Output
Black (-) Chassis Ground
Red/White (-) 200mA Channel 2 Auxiliary Output
White/Red (+) Activation Input
Gray/Black (-) Wait-to-Start Input
White/Blue (-) Activation Input
Yellow (+) Ignition Output
Green/White (-) Factory Alarm Rearm
Lt. Green/Black (-) Factory Alarm Disarm
4-Pin Harness
Wire Color Function
Pink (-) 200mA 3rd Ignition Output
Violet (-) 200mA Starter Output
Orange (-) 200mA 2nd Accessory Output
Blue (-) Status Output
5-Pin Harness
Wire Color Function
Black/White (-) Neutral Safety Input
Violet/White Tachometer Input
Brown (+) Brake Shutdown Input
Gray (-) Hoodpin Shutdown Input
Blue/White (-) 200mA 2nd Status / Rear Defogger Output
Relay Satellite
Wire Color Function
Red (+) 12v Constant Input
Pink (+) Ignition Output
Violet (+) Starter Output
Orange (+) Accessory Output
Red (+) 12v Constant Input
Pink/White (+) 2nd Ignition Output
3-Pin 2-Wire Door Lock Harness
Wire Color Function
Green (-) Lock
Empty
Blue (-) Unlock
