Ungo ProSecurity K20 - Page 33

Ungo ProSecurity
154
S100: Security/Keyless Entry System
Main Harness
Wire Color Function
Orange Ground When Armed (-) 500mA
White (+/-) Parking Light Output
White/Blue (-) 200mA Channel 3 Validity Output
Black/White (-) 200mA Domelight Supervision Output
Green (-) Door Trigger Input
Blue (-) Instant Trigger Input
Violet (+) Door Trigger Input
Black (-) Chassis Ground
Yellow (+) Ignition Input
Brown (+) Siren Output
Red (+) Constant Power
Red/White (-) 200mA Channel 2 Auxiliary Output
3-Pin 2-Wire Door Lock Harness
Wire Color Function
Green (-) Lock, (+) Unlock Output
Empty
Blue (-) Unlock, (+) Lock Output
S400: Security/Keyless Entry System
Main Harness
Wire Color Function
Orange Ground When Armed (-) 500mA
White (+/-) Parking Light Output
White/Blue (-) 200mA Channel 3 Validity Output
Black/White Domelight Supervision Output
Green (-) Door Trigger Input
Blue (-) Instant Trigger Input
Violet (+) Door Trigger Input
Black (-) Chassis Ground
Yellow (+) Ignition Input
Brown (+) Siren Output
Red (+) Constant Power
Red/White Channel 2 Auxiliary Output
8-Pin Harness
Wire Color Function
Violet Unlock #87 Normally Open (Input)
Blue/Black Unlock #30 Common (Output)
Brown/Black Unlock #87A Normally Closed
Violet/Black Lock #87 Normally Open (Input)
Green/Black Lock #30 Common (Output)
White/Black Lock #87A Normally Closed
Black/White Domelight Supervision Relay Input #87
Red/White Channel 2 Relay Input #87
