Ungo ProSecurity
155
S660: 2-Way Security/Keyless Entry System
Main Harness
Wire Color Function
Orange Ground When Armed (-) 500mA
White (+/-) Parking Light Output
White/Blue No Function
Black/White (-) Domelight Supervision Output
Green (-) Door Trigger Input
Blue (-) Instant Trigger Input
Violet (+) Door Trigger Input
Black (-) Chassis Ground
Empty
Brown (+) Siren Output
Red (+) Constant Power
Red/White (-) Channel 2 Auxiliary Output
7-Pin Harness
Wire Color Function
Empty
Empty
Empty
Empty
Empty
Yellow (+)Ignition Input
Empty
6-Pin Harness
Wire Color Function
Lt. Green/Black (-) Factory Alarm Disarm
Gray/Black No Function
Green/White (-) Factory Alarm Rearm
Violet/Black (-) 200mA Channel 4 Output
White/Black (-) 200mA Channel 5 Output
Lt. Blue (-) 2nd Unlock Output
3-Pin 2-Wire Door Lock Harness
Wire Color Function
Green (-) Lock
Empty
Blue (-) Unlock
