Ungo ProSecurity
157
SR1000: Remote Start/Security/Keyless Entry System
(continued)
5-Pin Harness
Wire Color Function
Black/White (-) Neutral Safety Input
Violet/White Tachometer Input
Brown (+) Brake Shutdown Input
Gray (-) Hoodpin Shutdown Input
Blue/White (-) 200mA Status/Defogger Output
6-Pin Harness
Wire Color Function
Lt. Green/Black (-) Factory Alarm Disarm Output
Gray/Black (-) Wait-to-Start Input
Green/White (-) Factory Alarm Rearm Output
Violet/Black (-) 200mA Channel 4 Output
White/Black (-) 200mA Channel 5 Output
Lt. Blue (-) 2nd Unlock Output
Relay Satellite
Wire Color Function
Purple (+) Starter Side Starter Wire (Output)
Green (+) Key Side Starter Wire (Input)
Red (+) 12v Constant Input
Orange (+) 12v Accessory Output
Red (+) 12v Constant Input
Pink (+) 12v Ignition Output
Red/White (+) 12v Constant Input
Pink/White (+) 12v Ignition 2 Output
4-Pin Harness on Relay Satellite
Wire Color Function
Pink (-) 200mA 3rd Ignition Output
Violet (-) 200mA 2nd Starter Output
Orange (-) 200mA 2nd Accessory Output
Blue (-) Status Output
3-Pin 2-Wire Door Lock Harness
Wire Color Function
Green (-) Lock, (+) Unlock Output
Empty
Blue (-) Unlock, (+) Lock Output
