SR5000: 2-Way Remote Start/Security/Keyless Entry System
Main Harness
Wire Color Function
Orange Ground When Armed (-) 500mA
White (+/-) Parking Light Output
White/Blue (-) Activation Input
Black/White (-) Domelight Supervision Output
Green (-) Door Trigger Input
Blue (-) Instant Trigger Input
Violet (+) Door Trigger Input
Black (-) Chassis Ground
Empty
Brown (+) Siren Output
Red (+) Constant Power
Red/White (-) Channel 2 Auxiliary Output
6-Pin Harness
Wire Color Function
Blue (-) 200mA Status/Factory Alarm Rearm Output
Blue/Black (-) 200mA 3rd Ignition Output
Gray (-) Hoodpin Shutdown Input
Brown (+) Brake Switch Shutdown Input
Violet/White Tachometer Input
Black/White (-) Neutral Safety Switch Input
3-Pin Harness
Wire Color Function
Gray/Black (-) Wait-to-Start Input
Lt. Green/Black (-) Factory Disarm/Special Accessory Output
Violet/Black (-) Programmable Channel 4 Output
Relay Satellite
Wire Color Function
Red (+) 12v Constant Input
Red (+) 12v Constant Input
Pink (+) 12v Ignition Output
Orange (+) 12v Accessory Output
Purple (+) 12v Starter Output
Pink/White (+) 12v 2nd Ignition Output
3-Pin 2-Wire Door Lock Harness
Wire Color Function
Green (-) Lock, (+) Unlock Output
Empty
Blue (-) Unlock, (+) Lock Output
