Model UT231: OPERATING MANUAL
20
To avoid damages to the Meter or harms to you, do
you measure higher than AC voltage 600V rms and
AC current 1000A rms.
Warning
To test for Apparent power (main display) + Reactive
power (secondary display), connect the Meter as follows:
Press the MENU to select Power factor (main
display) + Phase angle (secondary display) range.
Press the lever to open the transformer jaw, and
clamp them to the power source or the tested
conductor.
Insert the red test lead to V input terminal and black
test lead to COM input terminal and connect them
to tbe live wire and neutrual wire of the tested circuit.
The double display shows the power factor value
and the phase angle value of the measured object.
When the power factor value is negative, it means
the loading is capacItive.
When the power factor value is positive, it means
the loading is inductive.
MAX and MIN are not valid when measuring power
1.
2.
3.
4.
5.
6.
7.
factor.
When testing has been completed, disconnect the
connection between the testing leads and the circuit
under test and remove testing leads from the input
terminals.
