Figure 8
Model UT231: OPERATING MANUAL
19
starts recording the maximum apparent power
value.
Press MAX/MIN again, the LCD displays MIN, it
starts recording the minimum apparent power value.
Press MAX/MIN again to show the present apparent
power value.
7.
8.
When testing has been completed, disconnect the
connection between the testing leads and the circuit
under test and remove testing leads from the input
terminals.
Note
E. Power Factor (main display) + Phase Angle
(secondary display) Measurement (see figure 8)
Brack
Red
