Model UT58D: OPERATING MANUAL
Measurement Operation(9)
( figure 8)
Warning
Make sure the tested inductance is far away from the
high electromagnetic to obtain accurate reading.
Inductance measurement has 4 measurement positions
on the rotary switch: 2mH, 20mH, 200mH and 20H.
To test for Inductance, connect the Meter as below:
1. According to the size of the tested object’s leads,
insert multi-purpose socket or test clip into the mA
and V terminal.
2. Set the rotary switch to an appropriate measurement
position in HLx range.
3. Insert the tested object into the corresponding jack
of the multi-purpose socket or connect the test clip
to the object being measured.
The measured value shows on the display.
F. Capacitance Measurement(see figure 8)
Warning
To avoid damage to the Meter or to the equipment
under test, disconnect circuit power and discharge
all high-voltage capacitors before measuring
capacitance.Use the DC voltage function to confirm
that the capacitor is discharged.
To avoid harms to you, never attempt to input voltages
higher than 60V DC or 30V rms in AC.

UNI-T UT58D Specifications

General

Data hold	Yes
Product type	Digital multimeter
AC current range	0.002 - 20 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 100000 nF
Basic accuracy (DC current)	±(0.8%+1)
Basic accuracy (DC voltage)	±(0.5%+1)
Basic accuracy (capacitance)	±(2.5%+5)
Dimensions (WxDxH)	88 x 39 x 179 mm
Battery voltage	9 V

Weight and Dimensions

Weight	350 g
