Model UT58D: OPERATING MANUAL
The Meter Structure (see figure 1)
1 LCD Display
2 POWER
3 HOLD Button.
4 Rotary Switch
5 COM Input Terminal
6 20A Input Terminal
7 mA Input Terminal
8 Other Input Terminal.
( figure 1)

UNI-T UT58D Specifications

General

Data hold	Yes
Product type	Digital multimeter
AC current range	0.002 - 20 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 100000 nF
Basic accuracy (DC current)	±(0.8%+1)
Basic accuracy (DC voltage)	±(0.5%+1)
Basic accuracy (capacitance)	±(2.5%+5)
Dimensions (WxDxH)	88 x 39 x 179 mm
Battery voltage	9 V

Weight and Dimensions

Weight	350 g
