UNI-T UT58D User Manual

Model UT58D: OPERATING MANUAL
24
Measurement Operation(11)
( figure 9)
To measure capacitance, connect the Meter as follows:
1. According to the size of the tested object’s leads, select
multi-purpose socket or test clip to insert into the mA
and V terminal.
2. Set the rotary switch to an appropriate measurement
position in Fcx range.
3. Insert the tested object into the corresponding jack of
the multi-purpose socket or connect the test clip to
the object being measured.
The measured value shows on the display.

UNI-T UT58D Specifications

General

Data hold	Yes
Product type	Digital multimeter
AC current range	0.002 - 20 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 100000 nF
Basic accuracy (DC current)	±(0.8%+1)
Basic accuracy (DC voltage)	±(0.5%+1)
Basic accuracy (capacitance)	±(2.5%+5)
Dimensions (WxDxH)	88 x 39 x 179 mm
Battery voltage	9 V

Weight and Dimensions

Weight	350 g
