UNI-T UT58D User Manual

25
Model UT58D: OPERATING MANUAL
Sleep Mode
To preserve battery life, the Meter automatically turns off
if you do not turn the rotary switch or press any button for
around 15 minutes. When the Meter is under sleep mode,
it consumes 10µA current.
To activate the Meter, press POWER for two times.
Operation of Hold Mode
Warning
To avoid possibility of electric shock, do not use Hold
mode to determine if circuits are without power. The
Hold mode will not capture unstable or noisy readings.

UNI-T UT58D Specifications

General

Data hold	Yes
Product type	Digital multimeter
AC current range	0.002 - 20 A
AC voltage range	2 - 1000 V
DC voltage range	0.2 - 1000 V
Capacitance range	20 - 100000 nF
Basic accuracy (DC current)	±(0.8%+1)
Basic accuracy (DC voltage)	±(0.5%+1)
Basic accuracy (capacitance)	±(2.5%+5)
Dimensions (WxDxH)	88 x 39 x 179 mm
Battery voltage	9 V

Weight and Dimensions

Weight	350 g
