Model UT804: OPERATING MANUAL
To measure DCmA current, set up the Meter as Figure
3-6 and proceed as follows:
1. Insert the red test lead into the µAmA terminal and
black test lead into the COM terminal.
2. Set the rotary switch to mA
. DC measurement is
default, or press SELECT button to select DC
measurement mode
3. Connect the test leads in serial with the object being
measured.
The measured value shows on the display.
It displays the RMS.
Figure 3-6. DCmA Currents Measurement
