32
Model UT804: OPERATING MANUAL
To measure ACmA current, set up the Meter as Figure
3-7 and proceed as follows:
1. Insert the red test lead into the µAmA terminal and
black test lead into the COM terminal.
2. Set the rotary switch to mA
. DC measurement
is default, press SELECT button to select AC
measurement mode
3. Connect the test leads in serial with the object being
measured.
The measured value shows on the display.
It displays the True RMS value
.
4.
When a ACV function is selected, you can press the
AC+DC button to view the AC + DC True RMS value
in the primary display. To exit, please EXIT button
.
Figure 3-7. ACmA Currents Measurement
