Model UT81B: OPERATING MANUAL
Figure 3-8. Continuity Test
To avoid harms to you, please do not attempt to
input voltage higher than 60V DC or 42V rms AC.
To avoid possible damages to the Meter or to the
devices under test, disconnect circuit power and
discharge all the high-voltage capacitors before
measuring continuity.
Warning
To test for continuity, set up the Meter as Figure 3-8
and do the following:

UNI-T UT81B Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	0.01 - 10000 kHz
AC current range	0.4 - 10 A
AC voltage range	4 - 750 V
DC voltage range	0.4 - 1000 V
Dimensions (WxDxH)	100 x 48 x 200 mm
Battery voltage	1.5 V

Weight and Dimensions

Weight	498 g
