12
Display Symbols(1) (see figure 2)
( figure 2)
No. Symbol Meaning
1
2
4
Indicates negative reading.
CHARGE
3
AC
Indicator for AC voltage or current.
The displayed value is the mean
value.
The battery is low.
Warning: To avoid false readings,
which could lead to possible electric
shock or personal injury, replace the
battery as soon as the battery
indicator appears.
Charge indicator.
The Meter is in the auto range
mode in which the Meter
automatically selects the range with
the best resolution.
Data hold is active.
5
The mode on,which display the
present value minus the stored
value.
6
7
8
The voltage unit when charging is on.
V
Model UT90C: OPERATING MANUAL
