1. Product Overview
 Product Series (Features and Technical Specifications)
 Front Panel
 Rear Panel
1.1 Product Series
UTL8200 series DC electronic load contains 2 models: UTL8211 and UTL8212.
Model
Channel quantity
Measurement range
Voltage
Current
Power
UTL8211
Single channel
0~150V
0~40A
0~400W
UTL8212
Dual channel
0~150V
0~20A
0~200W
The UTL8200 series electronic load has a 2.8 inch LCD display. It is convenient to operate,
stylish in appearance, and supports dual-channel independent testing. The electronic load
has a wide power measurement range, the voltage and current measurement speed is up
to 40 kHz, the test resolution can reach 1mV/1mA, and it has various test functions and
modes for users to choose. The instrument can be configured with RS232 communication
module to flexibly meet on-site test conditions, and is convenient to connect with
automated production lines and automatic test systems (ATS).
1.1.1 Features
 Four basic test modes: CC/CV/CR/CP
 High resolution of 1mV/1mA
 Minimum rise time of dynamic current test: 500us
 Voltage and current measurement speed up to 40kHz
 Multi-mode battery discharge test
 List mode, support automatic test
 Independent short-circuit test function
 Protections of over-voltage/ under-voltage/ over-current/ over-power/ overheat/ anti-
reverse connection
 Support RS232 communication interface
 Configured with upper computer software for remote control and monitoring
 Power-off memory function
 Intelligent temperature-controlled fan
 Chinese/English interface
