Unical !DEA CS 24 PLUS el

27
Istruzioni per l’installazione
ITALIANO
Le pressioni al bruciatore riportate nella seguente tabella devono essere vericate dopo 3 minuti di funzionamento
e per modelli S (TFS) sono riferiti con camera di combustione chiusa.
TABELLA UGELLI - PRESSIONI - DIAFRAMMI - PORTATE
!DEA RS 24 el - IDEA CS 24 el
Tipo di
Gas
Potenza
Utile
[kW]
Portata
Termica
[kW]
Pressione
Aliment.
[mbar]
Ø
Ugelli
[mm]
Ugelli
n°
Ø Dia-
framma
[mm]
Pressione
minima
[mbar]
Pressione
massima
[mbar]
Consumi
min.
Consumi
max.
Gas nat. (G20) 10,1- 24,6 11,5 - 26,5 20 1,35 11 - 2,3 12,8 1,22 m³/h 2,80 m³/h
Propano (G31) 10,1- 24,6 11,5 - 26,5 37 0,85 11 - 6,1 33,5 0,89 kg/h 2,06 kg/h
!DEA CS 24 PLUS el
Tipo di
Gas
Potenza
Utile
[kW]
Portata
Termica
[kW]
Pressione
Aliment.
[mbar]
Ø
Ugelli
[mm]
Ugelli
n°
Ø Dia-
framma
[mm]
Pressione
minima
[mbar]
Pressione
massima
[mbar]
Consumi
min.
Consumi
max.
Gas nat. (G20) 10,1- 24,7 11,5 - 26,5 20 1,35 11 - 2,3 12,80 1,22 m³/h 2,80 m³/h
Propano (G31) 10,1- 24,7 11,5 - 26,5 37 0,85 11 - 5,8 32 0,89 kg/h 2,06 kg/h
!DEA RS 28 el - IDEA CS 28 el
Tipo di
Gas
Potenza
Utile
[kW]
Portata
Termica
[kW]
Pressione
Aliment.
[mbar]
Ø
Ugelli
[mm]
Ugelli
n°
Ø Dia-
framma
[mm]
Pressione
minima
[mbar]
Pressione
massima
[mbar]
Consumi
min.
Consumi
max.
Gas nat. (G20) 10,2- 28,0 11,5 - 30,1 20 1,30 13 - 2,0 13,3 1,22 m³/h 3,18 m³/h
Propano (G31) 10,2- 28,0 11,5 - 30,1 37 0,85 13 - 4,4 29,0 0,89 kg/h 2,34 kg/h
!DEA CS 32 el - IDEA RS 32 el
Tipo di
Gas
Potenza
Utile
[kW]
Portata
Termica
[kW]
Pressione
Aliment.
[mbar]
Ø
Ugelli
[mm]
Ugelli
n°
Ø Dia-
framma
[mm]
Pressione
minima
[mbar]
Pressione
massima
[mbar]
Consumi
min.
Consumi
max.
Gas nat. (G20) 11,6 31,6 13,5 - 34,5 20 1,30 15 - 1,8 13,3 1,43 m³/h 3,65 m³/h
Propano (G31) 11,6- 31,6 13,5 - 34,5 37 0,85 15 - 4,4 29,0 1,05 kg/h 2,68 kg/h
!DEA CS 28 Plus el
Tipo di
Gas
Potenza
Utile
[kW]
Portata
Termica
[kW]
Pressione
Aliment.
[mbar]
Ø
Ugelli
[mm]
Ugelli
n°
Ø Dia-
framma
[mm]
Pressione
minima
[mbar]
Pressione
massima
[mbar]
Consumi
min.
Consumi
max.
Gas nat. (G20) 10,2- 28,1 11,5 - 30,1 20 1,30 13 - 2,0 13,3 1,22 m³/h 3,18 m³/h
Propano (G31) 10,2- 28,1 11,5 - 30,1 37 0,85 13 - 4,4 29 0,89 kg/h 2,34 kg/h
!DEA CS 32 Plus el
Tipo di
Gas
Potenza
Utile
[kW]
Portata
Termica
[kW]
Pressio-
ne
Aliment.
[mbar]
Ø
Ugelli
[mm]
Ugelli
n°
Ø Dia-
framma
[mm]
Pressione
minima
[mbar]
Pressione
massima
[mbar]
Consumi
min.
Consumi
max.
Gas nat. (G20)
12,2 - 32,3 13,5 - 34,5
20 1,30
15
-
1,8
13,3
1,43 m³/h 3,65 m³/h
Propano (G31)
12,2 - 32,3 13,5 - 34,5
37 0,85
15
-
4,4
29
1,05 kg/h 2,68 kg/h
