Maintenance instructions

ENGLISH

Inspections and maintenance performed

professionally and according to a regular

schedule, as well as the use of original

spare parts, are of the utmost importance

for fault-free operation of the b oiler and

to guarantee its long life.

The maintenance frequency must comply

with standards in force.

Failure to perform Inspections and Main-

INSPECTION AND

MAINTENANCE

4.1 - INSPECTION AND MAINTE-

NANCE INSTRUCTIONS

To assure long-term functioning of yo ur b oiler and to

av oid altering its approv ed status, only original Unical

spare parts must b e used.

If a component needs to b e replaced:

• Disconnect the appliance from the electrical mains

and mak e sure that it cannot b e reconnected

accidentally .

• Close the gas shut-off valve upstream the boiler.

• If needed, and depending on the intervention to

b e carried out, close any shut-off va lve s on the

ow and return line of the heating system, as well

as the cold water inlet va lve .

• Remove the front casing from the appliance.

Once all maintenance operations are complete

resume b oiler operation

• Open the heating ow and return pipes, as well

as the cold water inlet v alv e ( if closed prev iously ).

• Vent and, if necessary, restore the heating pres-

sure until reaching a pressure of 0.8/1.0 b ar.

• Open the gas shut-off valve.

• Switch the boiler back on.

• Make sure the appliance is gas tight and water-

tight.

• Remount the front casing of the appliance.

tenance can entail material and personal

damage

TABLE OF RESISTANCE VALUES, ACCORDING TO THE TEMPERATURE, TO THE HEATING PROBE 11 ( SR)

AND TO THE DOMESTIC HOT W ATER PROBE 1 ( SS) AND ANY HEATING RETURN PROBE 22 ( SRR) see par. 4.5.

T°C0123456789

0 32755 31137 29607 28161 26795 25502 24278 23121 22025 20987

10 20003 19072 18189 17351 16557 15803 15088 14410 13765 13153

20 12571 12019 11493 10994 10519 10067 9636 9227 8837 8466

30 8112 7775 7454 7147 6855 6577 6311 6057 5815 5584

40 5363 5152 4951 4758 4574 4398 4230 4069 3915 3768

50 3627 3491 3362 3238 3119 3006 2897 2792 2692 2596

60 2504 2415 2330 2249 2171 2096 2023 1954 1888 1824

70 1762 1703 1646 1592 1539 1488 1440 1393 1348 1304

80 1263 1222 1183 1146 1110 1075 1042 1010 979 949

90 920 892 865 839 814 790 766 744 722 701

Relation b etw een the temperature ( °C) and the nom. resistance ( Ohm) of the heating prob e SR and of the domestic hot

w ater prob e SS

Eample: At 25°C, the nominal resistance is 10067 Ohm At 90°C,the nominal resistance is 920 Ohm
