ATTENTION!
Function reserved for Unical AG S.p.A.
Authorised Assistance Centres only.
Some servi ce parameters can b e edited
from the control panel:
4.2 - PARAMETERS THAT CAN BE EDITED FROM THE CONTROL PANEL
service
MAX
M
I
N
service
MAX
M
I
N
service
MAX
M
I
N
service
1 ACTIVATION
B y pressing the b utton ( D) for 10 seconds, the
function is activated when the key ashes on the
display
MAX IMUM HEATING OUTPUT
VALUES
FROM A DEFAULT
0 ( Min) 99 ( Max) 99
EX TERNAL PROBE TEMPERATURE
VALUES
FROM A DEFAULT
0 ( - 20°C) 30 ( + 10°C) 20 ( 0°C)
NUMBER OF SW ITCH-ONS LIMIT DEVICE
VALUES
FROM A A DEFAULT
0 ( * ) 1 ( minute)
15 ( minutes)
0
( * ) W ITH VARIAB LE HY STERESIS
PUMP POST CIRCULATION
VALUES
FROM A DEFAULT
0 ( 5 min) 1 ( ALW AY S) 0 ( 5 min)
SELECTION
Turn the HEATING kn ob ‘’B ’’
EDITING THE VALUE
Turn the DOMESTIC HOT W ATER kn ob ‘’C’’
The value ashes on the display
CONFIRM SELECTION
Conrm the parameter to be edited by pressing
the unb lock ke y
CONFIRM VALUE
Conrm the value by pressing the unblock key
PARAMETER SELECTION
Go b ack to section 2.
DISABLING
To ex it the parameters list
wait for 20” or quick ly turn
the domestic hot water
kn ob ‘‘C’’.
