10 EX HAUST PIPE
DIFFICULT
TN: Check the ue draught or the ue gas
thermostat ( 7) .
TFS: Check the operation of the fan and
its pressure switch ( 18 ) ( 19 ) .
Any ue obstructions. Make sure the ue
gas exh aust collector is not present with
longer lengths than the manufacturer limit.
serv ice
13 BLOCK
No gas or failed b urner ignition
Check the gas supply and that the ignition/
detection electrode is work ing properly .
P ressure shut-off va lve s.
serv ice
14 PARASITE FLAME
Flame detected upon ignition
( 4 )
Check the wiring of the Ign/Det. electrode
and remove any oxi dation, press the un-
b lock ke y , if the anomaly persists, replace
the electrode.
serv ice
16 INTERNAL ERROR Replace the electronic b oard
serv ice
17 LOW VOLTAGE
P ower supply vo ltage too low
serv ice
19 ERROR
CONFLICT
FIRMW ARE
Replace the electronic b oard
serv ice
20 ERROR
CIRCUIT
FLAME
Replace the electronic b oard
serv ice
21 ERROR
DRIVER VALVE
GAS
Replace the electronic b oard
serv ice
23 ERROR
MEMORY
INTERNAL
Replace the electronic b oard
serv ice
23 ERROR
RESET B UTTON ALW AY S ACTIVE
Check if the b utton is j ammed or glued to
the b oard.
serv ice
23 EX CESSIVE NUMBER OF
REMOTE RESETS
The error code appears after 5 resets in
15 minutes
Disconnect and connect vo ltage to delete
the error code.
serv ice
