UniCarriers FD30T3C - SERVICE DATA

SERVICE DATA
• Standard settings for the engines
Gasoline engine Diesel engine
K21 V2403 C240
Idle
(rpm) 700 825 700
No-load maximum
(rpm)
3100 2820 2750
Ignition order 1-3-4-2 – –
Ignition timing
(BTDC/rpm)
2°/700 – –
Spark plug gap
(mm) 0.8 - 0.9 – –
Spark plug type FR2A-D – –
Fuel injection order – 1-3-4-2 1-3-4-2
Fuel injection timing
BTDC
– 15.5° - 17° 9°
Fuel injection start
pressure
MPa (kgf/cm
2
)
– 13.7(140)
11.76
(120)
Compression pressure
MPa (kgf/cm
2
)/rpm
1.45
(14.8)/250
3.2 - 3.7
(33 - 38)/300
3.0
(31)/200
Valve clearance (both
intake and exhaust
valves)
(mm)
0.38
(when
warm)
0.18 - 0.22
(when
cold)
0.45
(when
cold)
Note: For the deection of the fan belt, see page 4-9.
• Tire ination pressure:
............................................................................................................See page 4-3.
• Lift chain deection:
.............. No difference in deection between both chains are allowed when they are pressed with the
thumbs of both hands at the same time.
• Steering wheel play (with engine running): ..................................................... 15 – 30 mm (0.6 – 1.2 in.)
• Pedal settings: ......................................................................................................................See page 4-14.
5-8
