UniCarriers FD30T3C - Bolt and Nut Torque; Service Data

Mast support cap bolts
148 – 223 N-m
(15.1 – 22.7 kgf-m)
(109 – 164 ft-lbs)
A: 100 – 120 N-m (10– 12 kgf-m)
B: 32 – 49 N-m (3.3 – 5 kgf-m)
Engine mount bolts
BOLT AND NUT TORQUE
Rear axle mount bolts
77 – 115 N-m
(7.85 – 11.7 kgf-m)
(57 – 85 ft-lbs)
5-9
SERVICE DATA
-m (10 - 12 kgf-m)
A
B
