UniCarriers FD30T3C - Page 149

Single tire
•
471 – 549 N-m (48 – 56 kgf-m)
(347 – 405 ft-lbs)
Double tires
•
471 – 549 N-m (48 – 56 kgf-m)
(347 – 405 ft-lbs)
Drive shaft mount bolts
96 – 111 N-m (9.8 – 11.3 kgf-m)
(71 – 82 ft-lbs)
Hub nuts (rear wheel)
128 – 190 N-m (13 – 19.4 kgf-m)
(94 – 140 ft-lbs)
Hub nuts (front wheel)
Inner nut
Outer nut
Single tire
Double tires
5-10
SERVICE DATA
