UNICORECOMM UM980 User Manual

UM980 User Manual
6 Hardware UC-00-M32 EN R1.1
2 Hardware
2.1 Dimensions
Table 2-1 Dimensions
Parameter
Min. (mm)
Typ. (mm)
Max. (mm)
A
21.80
22.00
22.50
B
16.80
17.00
17.50
C
2.40
2.60
2.80
D
3.75
3.85
3.95
E
0.95
1.05
1.15
F
1.80
1.90
2.00
G
1.00
1.10
1.20
H
0.70
0.80
0.90
K
1.40
1.50
1.60
M
3.55
3.65
3.75
N
3.15
3.25
3.35
P
2.00
2.10
2.20
R
1.00
1.10
1.20
X
0.72
0.82
0.92
