2.3.3 IO Threshold
Table 2-5 IO Threshold
Parameter
Symbol
Min.
Typ.
Max.
Unit
Condition
Low Level
Input Voltage
V
in_low
0
0.6
V
High Level
Input Voltage
V
in_high
VCC × 0.7
VCC + 0.2
V
Low Level
Output Voltage
V
out_low
0
0.45
V
I
out
= 2 mA
High Level
Output Voltage
V
out_high
VCC -
0.45
VCC
V
I
out
= 2 mA
2.3.4 Antenna Feature
Table 2-6 Antenna Feature
Parameter
Symbol
Min.
Typ.
Max.
Unit
Condition
Optimum Input
Gain
G
ant
18
30
36
dB
