Dynamic Orbs GMP Manual
09/26/2023
18
Communication：
Item
Content
Content
485(J14)
B
Big ball reader A
A
Big ball reader B
GND
B
A
GND
USART(J11) (MCU)
RX
TX
GND
USART(J12) (232)
RX
Motor drive board TX
TX
Motor drive board RX
GND
USART(J13) (232)
RX
TX
GND
USART(J8) (232)
RX
TX
GND
GND
USB
